Key Features
- Direct integration/plug and play with our Skystars F722 and F405 flight series controllers.
- Variable PWM Frequency: Customize PWM frequency for precise motor control.
- Firmware Upgradeability: Seamless updates via Betaflight passthrough.
- Motor Protocol Support: Compatible with Servo PWM and Dshot (300, 600) motor protocols.
- Bi-directional Dshot: Enhance control and telemetry with bidirectional communication support.
- Telemetry Support: Betaflight ESC telemetry, KISS standard ESC telemetry.
- Sinusoidal Startup Mode: Smooth acceleration for larger motors.
Specifications:
Input voltage: 3-6S LiPo
Con.Current: 60A
Peak Current: 70A≥ 10S
Firmware: AM_32
Support: Dshot 600/1200
Mounting hole : 30.5X30.5 mm/M3
BEC: No
Product size: 41*46*7.6mm
Weight: 18g
Includes
1x Skystars AM60 AM_32 60A 32Bit 3-6S 30.5mm 4in1 ESC
4X Silicon grommets M3X3.5mm
1 x XT60 Connected Cable
1 x Cable
1 x Capacitor 35V 560uF
